RX-TX SYSTEM

> PA > RX-TX SYSTEM

PRODUCT FEATURES: ■features

▶In accordance with Article 5, Subparagraph 1 of the Fire
Safety Standard NFSC 202, this product is the most suitable
for ensuring that fire notifications on other floors are not
hindered even if a loudspeaker or wiring on one floor is
short-circuited or disconnected; it disconnects only the
short-circuited or disconnected line while maintaining
normal broadcasting on other lines.
▶It has up to 16 channels, and by checking speaker line
impedance, it provides a buzzer alarm and displays on
the LCD screen (line open, overimpedance, under-impedance,
line short, impedance, etc.) in the event of an abnormality,
allowing the user to respond more accurately and quickly.
▶Real-time checking is possible through automatic checking
based on time settings and contact reception in case of fire.
▶You can check the selection of 2-wire and 3-wire speaker lines.
